The TG9000 tub grinder packs innovation and power for the large land-clearing projects and organic/wood waste processing applications.

Find A Dealer Request More Info
When you need maximum power for your high-production grinding operation, the TG9000 is an ideal choice. The TG9000 features a large-diameter opening of 11 ft (3.4 m) inside the tub. The patented Series III duplex drum offers proven cutting performance and reversible hammers and tips that maximize the wear life of single-sided designs and make daily maintenance efficient.

The TG9000 tub grinder packs innovation and power for the large land-clearing projects and organic/wood waste processing applications.

When you need maximum power for your high-production grinding operation, the TG9000 is an ideal choice. The TG9000 features a large-diameter opening of 11 ft (3.4 m) inside the tub. The patented Series III duplex drum offers proven cutting performance and reversible hammers and tips that maximize the wear life of single-sided designs and make daily maintenance efficient. Find A Dealer Request More Info

Features & Benefits

Engine power

A CAT C32 Tier 4 Stage V engine provides 1,125 hp (838 kW) of power to meet your jobsite demands.

Optimal cutting performance

The patented Series III duplex drum offers proven cutting performance, and reversible hammers and tips nearly double the wear life of single-sided designs, simplifying daily maintenance.

Jobsite safety

The thrown object restraint system (TORS) reduces the amount and distance of thrown material debris and has a smooth underside of optimal material flow.

Precise placement

The radial stacking rear discharge conveyor oscillates 60 degrees, allowing the operator to place the processed material where they need it without moving the machine.

Convenient control

Make machine adjustments or monitor real-time performance and data via the machine control panel or the handheld transceiver remote.

High production

Smooth, 63-in (160-cm) belt enables high-volume product removal and is constructed of 0.5-in (1.3-cm) thick rubber to help resist tearing and puncturing.

Specifications

Compare Models
Show Metric
  • General Dimensions and Weights - Non Loader

    • Maximum Length - Transport 46 ft 14 m
    • Maximum Length - Conveyor Unfolded 72 ft 21.9 m
    • Maximum Width (Transport) 11.9 ft 3.6 m
    • Maximum Height (Transport) 165 in 419.1 cm
    • Weight - Engine Option One 106000 lbs 48080.8 kg
    • King pin weight - Engine option one 35000 lbs 15875.7 kg
    • Axle Weight 71000 lbs 32205.1 kg
    • Sound Power Sound power LwA = 118.4 dB(A), at the control panel = 86.4 dB(A)
  • Engine - Option one

    • Make and Model CAT C32 Tier 4 Final/Stage V
    • Number of Cylinders 12
    • Gross Horsepower (Maximum) 1125 hp 838.9 kw
    • Torque (Max) 4056 ft-lb 5499.2 Nm
    • Fuel Tank Capacity 600 gal 2271.2 L
    • Max Fuel Consumption 55.2 gph 209 lph
    • Fuel Type Ultra-low sulfur diesel
    • Air Cleaner Three stages - pre-cleaner, primary element and secondary element
    • Oil Filter Spin-on (2)
    • Recommended Oil CAT DEO-ULS, API CJ-4, API CK-4 or ECF-3 10W-30/15W-40
    • Oil Volume with Filter 72 qt 68.1 L
    • Cooling Medium Liquid
    • Coolant Capacity (Engine and Radiator) 53 gal 200.6 L
    • Air to Boil Temperature 127 deg
    • Alternator 24 V
    • Fan 60-in (152.4-cm) diameter, fixed pitch, hydraulic reverse, variable speed
    • Clutch Type Hydraulic-operated wet clutch
    • Clutch Engagement Switch or button
  • Feed System

    • Tub Table Thickness 0.5 in (1.3 cm)
    • Tub Table Type T1 steel
    • Table Tilt Degrees 93 deg
    • Millbox Opening 32 in x 70 in (81.3 cm x 177.8 cm)
    • Inside Diameter of Tub 11 ft 3.4 m
    • Inside Flare Diameter - At Base of Tub 11.4 ft 3.5 m
    • Inside Flare Diameter - At Tub Opening 13 ft 4 m
    • Depth of Tub 4.6 ft 1.4 m
    • Tub Capacity 17 cu yd 13 cu m
    • Wall Thickness .4 in 1 cm
    • Wall Type Grade 50 plate
    • Loading Height 11.3 ft 3.4 m
    • Drive Type Closed loop hydraulic, continuous sprocket
    • Drive Chain ANSI #160 roller chain
    • Drive Tensioner Compression spring
    • Drive Motor Hydraulic, low speed/high torque (qty 2)
    • Tub Roller Quantity Eight carrier, eight guide (qty 16)
    • Tub Agitators 4
  • Safety System

    • Thrown Object Restraint System Pivoting tub cover assembly
    • Tub Cover Description Conical cover with hydraulic swing away
    • Tub Cover Positions Transport and operate with hydraulic lock
    • Rotor Deflector Standard
    • Wear Liner Thickness .8 in 2 cm
    • Wear Liner Type Abrasion-resistant plate (AR400), hardfaced
    • Falling Object Protection at Control Station Overhead and side protection
  • Duplex Drum

    • Drum Diameter 28 in 71.1 cm
    • Tip Diameter 36.4 in 92.5 cm
    • Drum Cutting Width 64 in 162.6 cm
    • Drum Skin Thickness 1.5 in 3.8 cm
    • Drum Speed 1269 rpm
    • Tip speed 12105 ft/min
    • Bearing Type Double row, spherical roller
    • Bearing - Inner Race Diameter 5.5 in 14 cm
    • Bearing - Dynamic Capacity 228000 lbs 103419.1 kg
    • Number of Hammers 10
    • Number of Cutters 20
    • Cutter Block Types Multiple styles, 2-bolt retention with 7/8-in (2.2-cm) UNC fasteners
    • Center Retention Pin Dimensions 2 in (5.1 cm)
    • Number of Wipers 4
  • Screens

    • Screen Weight 500-800 lb (226-362 kg)
    • Screen Dimensions 72 in x 38 in x 1.0 in (182.9 cm x 96.5 cm Ø x 2.5 cm)
    • Screen Type AR400, reversible (qty 2)
    • Breaker Bar Type T1 steel, repleaceable
    • Breaker Bar Dimensions 2.5 in x 4 in x 77 in (6.4 cm x 10.2 cm x 195.6 cm)
    • Number of Sides Four usable edges
    • Screen Area 5100 sq in 32903.2 sq cm
    • Distance - Screen to Millbox Wall 19 in 48.3 cm
  • Driveline - Engine Option One

    • Drive Shaft Custom
    • U - Joints 10C, greaseable
  • Discharge system - Dual belt, radial stacking design

    • Length Discharge - 30 ft (9.1 m)
    • Belt width Discharge - 48 in (121.9 cm), belly - 60 in (152.4 cm)
    • Belt Design Discharge - 220# V-cleat, belly - 330# smooth
    • Splice Discharge and belly - Flexco R2 stainless steel
    • Return Roller Quantity 5 standard and 1 vibrating roller
    • Idler roller diameter Discharge and belly - 10 in (25.4 cm)
    • Idler Roller Bearing Discharge and belly - 2.93 in (4.9 cm), 4-bolt flange
    • Drive Roller Diameter 14 in 35.6 cm
    • Magnetic Drive Roller Diameter 14 in 35.6 cm
    • Drive Motor Geroler
    • Belt speed Discharge - 0-1060 fpm (0-323 m/min); belly - 0-744 fpm (0-227 m/min)
    • Load Height 13-18 ft (4-5.5 m)
    • Swing arc +/- 30 degrees, 60 degrees total
  • Hydraulic System

    • Tank capacity 100 gal 378.5 L
    • Recommended Oil Hy-power 68
    • Filtration Method In-tank return filters (qty 2)
    • Number of Coolers 1
  • Implement Hydraulics

    • System Type Open loop
    • Pump Type Gear pump
    • System relief pressure 3000 psi 206.8 bar
  • Tub Drive Hydraulics

    • System Type Closed loop
    • Pump Type Axial piston, variable displacement
    • Pump Flow at Maximum RPM 44.5 gpm 168.5 L/min
    • System relief pressure 4000 psi 275.8 bar
    • Motor Series Geroler, heavy-duty high-torque (qty 2)
  • Fan Drive Hydraulics

    • System Type Closed loop
    • Pump Type Axial piston, variable displacement
    • Pump Flow at Maximum RPM 43.4 gpm 164.3 L/min
    • System relief pressure 5000 psi 344.7 bar
    • Motor Series Axial piston, variable displacement
    • Fan Series - FWD/REV 1180 rpm/500 rpm
  • Clutch Hydraulics

    • Tank capacity 20 gal 75.7 L
    • Recommended Oil VMF ultra gold
    • Filtration Method Spin-on pressure
    • Number of Coolers 1
    • System Type Open loop
    • Pump Type Gear
    • Pump Flow at Maximum RPM 10.1 gpm 38.2 L/min
    • System relief pressure 250 psi 17.2 bar
  • Electrical System

    • System Voltage 24 V
    • Battery Group 8-D, 1400 CCA (qty 2)
    • System Protection Fused
  • Control Station

    • Display Type LCD multi-function
    • Engine Information Operational, diagnostic and system parameters
    • Machine Information Operational, diagnostic and system parameters
    • Operational Faults SAE J1939 diagnostic codes
    • Gauges Tub pressure, conveyor pressure, auxiliary hydraulic pressure, clutch pressure
    • Switches Moisture proof, toggle style
  • Radio Remote Control

    • Display Type LCD multi-function
    • Engine Information Operational, diagnostic and system parameters
    • Machine Information Operational, diagnostic and system parameters
    • Operational Faults SAE J1939 diagnostic codes
    • Switches Sealed membrane
    • Operating Range 300 ft (91.4 m)
    • Battery Type AA (qty 6)
    • Channel Setting 50 channels
  • Chassis

    • Frame Description Fabricated I-beam
    • Hitch Type Bolt-in kingpin - 2 in (5.1 cm)
    • Fender Description Bolt-on, 3/16-in (0.5-cm) formed steel
    • Brake Type Air actuated with spring-applied park brake
    • Trailer Light Type 12V incandescent
  • Axle/Suspension

    • Axle Type Quad-axle leaf spring
    • Tires - Option One 255/70R22.5 duals
    • Wheels - Option One 22.5-in x 8.25-in (57.2-cm x 21.1-cm) hub-piloted steel
    • Ground Clearance - Option One 9 in 22.9 cm
  • Optional Air Compressor

    • Air Compressor Brand Mi-T-M
    • Engine 11.7 hp (8.7 kW) Honda
    • Maximum Pressure 175 psi 12.1 bar
    • Maximum Air Flow 29 cfm .8 cmm
    • Tank capacity 30 gal 113.6 L
  • Other Options - Tub Grinder

    • Screens Optional
    • Special Tools Group Optional
    • Special Paint Optional
    • Extended Warranty Optional
    • Preventative Maintenance Optional
