The TG5000 tub grinder from Vermeer is your machine for powerful processing in a convenient package, with a 540 hp (403 kW) engine and optional loader with grapple. With the new Series III duplex drum, the TG5000 offers proven cutting performance with enhanced durability and serviceability. Look to the TG5000 for productivity and efficiency for your toughest jobs.

Powerful processing. Convenient package.

The TG5000 tub grinder from Vermeer is your machine for powerful processing in a convenient package, with a 540 hp (403 kW) engine and optional loader with grapple. With the new Series III duplex drum, the TG5000 offers proven cutting performance with enhanced durability and serviceability. Look to the TG5000 for productivity and efficiency for your toughest jobs.

Find A Dealer Request More Info

Features & Benefits

Proven cutting performance

The new Series III duplex drum is built off the proven cutting performance of previous Vermeer duplex drum designs, and makes maintenance more convenient with enhancements such as an independently secured wedge system and enhanced drum balancing.

Optional loader cab

An optional loader cab with grapple increases efficiency and can lift up to 3500 lb (1587.6 kg) at full reach.

Electric-over-hydraulic controls

The loader’s electric-over-hydraulic controls provide the flexibility for an operator to use their preferred control configuration (Vermeer, SAE or ISO), as well as three operating modes with varying joystick sensitivity to meet the operator’s needs.

Multiple engine options

The TG5000 is powered by a 540 hp (403 kW) Caterpillar C15 Tier 4 Final engine. A Tier 3 engine option is available for lesser-emission regulated countries.

Thrown Object Restraint System (TORS)

The patented Thrown Object Restraint System (TORS) reduces the amount and distance of thrown objects, and has a smooth underside for better material flow.

Improved efficiencies

With features such as a hydraulically driven variable flow and reversing Flexxaire cooling fan, the TG5000 is built with operating efficiency top of mind. The fan adjusts the pitch of the blades based on temperature, which can increase the power available to the mill for better processing efficiency.

Specifications

Compare Models
Show Metric
  • General Dimensions and Weights - Non Loader

    • Maximum Length - Transport 39.2 ft 12 m
    • Maximum Length - Conveyor Unfolded 61.1 ft 18.6 m
    • Maximum Width (Transport) 8.4 ft 2.6 m
    • Maximum Height (Transport) 13.1 ft 4 m
    • Weight - Tandem Axle 51000 lbs 23133.2 kg
    • Weight - Triple Axle 53000 lbs 24040.4 kg
    • Tongue Weight - Tandem Axle 16500 lbs 7484.3 kg
    • Tongue Weight - Triple Axle 16000 lbs 7257.5 kg
    • Axle Weight - Tandem Axle 34500 lbs 15648.9 kg
    • Axle Weight - Triple Axle 37000 lbs 16782.9 kg
    • Sound Power Sound Power LwA=116.6 dB(A) At the lower control panel = 96.4 dB(A)
  • General Dimensions and Weights - Loader

    • Maximum Length - Transport 45.5 ft 13.9 m
    • Maximum Length - Conveyor Unfolded 67.5 ft 20.6 m
    • Maximum Reach of Loader 27 ft 8.2 m
    • Maximum Width (Transport) 8.4 ft 2.6 m
    • Maximum Height (Transport) 13.1 ft 4 m
    • Maximum Height - Cab in Operating Position 18.8 ft 5.7 m
    • Weight - Engine Option One 68000 lbs 30844.3 kg
    • Weight - Triple Axle 68000 lbs 30844.3 kg
    • Tongue Weight - Engine Option One 24000 lbs 10886.2 kg
    • Axle Weight 44000 lbs 19958.1 kg
    • Sound Power Sound Power LwA=116.6 dB(A) At the lower control panel = 96.4 dB(A) In the loader cab = 76.8 dB(A)
  • Engine - Option one

    • Make and Model CAT C15 T4F Stage V
    • Number of Cylinders 6
    • Gross Horsepower (Maximum) 540 hp 402.7 kw
    • Torque (Max) 1823.3 ft-lb 2472.1 Nm
    • Fuel Tank Capacity 251 gal 950.1 L
    • Max Fuel Consumption 28 gph 106 lph
    • Fuel Type Ultra Low Sulfur Diesel
    • Air Cleaner Primary & Secondary Backup Filter with precleaner and electric restriction indicator
    • Oil Filter Spin-on
    • Recommended Oil CAT DEO-ULS OR API CJ-4, OR ACEA E9. CAT LABEL 350-0684 IS RECOMMENDED
    • Oil Volume with Filter 40.2 qt 38 L
    • Cooling Medium Liquid
    • Coolant Capacity (Engine and Radiator) 20 gal 75.7 L
    • Air to Boil Temperature 125 deg
    • Alternator 24 Volt, 190 Amp
    • Fan 42" Dia, Variable Pitch, Reversible
    • Clutch Type PT Tech
    • Clutch Engagement Push Button
  • Engine - Option two

    • Make and Model CAT C15 Tier 3
    • Number of Cylinders 6
    • Gross Horsepower (Maximum) 540 hp 402.7 kw
    • Torque (Max) 1819 ft-lb 2466.2 Nm
    • Fuel Tank Capacity 251 gal 950.1 L
    • Max Fuel Consumption 27 gph 102.2 lph
    • Fuel Type Diesel
    • Air Cleaner Primary & Secondary Backup Filter with precleaner and electric restriction indicator
    • Oil Filter Spin-on
    • Recommended Oil API CC/CD
    • Oil Volume with Filter 42 qt 39.7 L
    • Cooling Medium Liquid
    • Coolant Capacity (Engine and Radiator) 24 gal 90.8 L
    • Alternator 24 Volt, 200 Amp
    • Fan 42" Dia, Fixed Pitch, Reversible
    • Clutch Type PT Tech
    • Clutch Engagement Push Button
  • Feed System

    • Tub Table Thickness 0.375 in (9.5 mm)
    • Tub Table Type T1 Steel
    • Table Tilt Degrees 91 deg
    • Millbox Opening 24.4 x 46.9 in (61.9 x 119.1 cm)
    • Inside Diameter of Tub 7.8 ft 2.4 m
    • Inside Flare Diameter - At Base of Tub 8.3 ft 2.5 m
    • Inside Flare Diameter - At Tub Opening 12.3 ft 3.7 m
    • Depth of Tub 5.1 ft 1.5 m
    • Wall Thickness .3 in .6 cm
    • Wall Type T1 Steel
    • Loading Height 10.7 ft 3.3 m
    • Drive Type Continuous sprocket
    • Drive Chain 120H roller chain
    • Drive Tensioner Automatic hydraulically tensioned mechanical slide
    • Drive Motor Open loop
    • Tub Roller Quantity 8 carrier, 8 guide
    • Tub Speed 10 rpm
    • Tub Agitators 4
  • Safety System

    • Thrown Object Restraint System Pivoting tub cover assembly
    • Tub Cover Description Hydraulically activated
    • Tub Cover Positions Transport and Operate with Hydraulic Lock. Transport also has mechanical lock
    • Rotor Deflector Standard
    • Falling Object Protection at Control Station Overhead and side protection
  • Duplex Drum

    • Drum Diameter 22.5 in 57.2 cm
    • Tip Diameter 29 in 73.7 cm
    • Drum Cutting Width 44 in 111.8 cm
    • Drum Skin Thickness 1.5 in 3.8 cm
    • Drum Speed 2050 rpm
    • Tip Speed 15612 rpm
    • Bearing Type Spherical roller
    • Bearing - Inner Race Diameter 4.3 in 11 cm
    • Bearing - Dynamic Capacity 136000 lbs 61688.6 kg
    • Number of Hammers 7
    • Number of Cutters 14
    • Cutter Block Types Block style single bolt wide 3"x3.5" wide; 2 bolt 2"x3" narrow
    • Center Retention Pin Dimensions 2"
    • Number of Wipers 4
  • Screens

    • Screen Dimensions 47" x 29" x 3/4"
    • Screen Type AR 400, Reversible, Qty 2
    • Breaker Bar Type Replaceable T1 Steel Bar
    • Breaker Bar Dimensions 2.5" x 3"
    • Number of Sides 4 Usable Edges
    • Screen Area 2700 sq in 17419.3 sq cm
  • Driveline - Engine Option One

    • Drive Shaft Custom 1810
    • U - Joints Greased (qty 2)
  • Discharge System - Single Belt Design

    • Width 36 in 91.4 cm
    • Belt Design Standard: 3-ply 330 V-Cleated Heavy Duty: Straight Warp Single Ply 330# both with V-cleat
    • Splice Standard: Armored Stainless Steel Cable Heavy Duty: Super Screw
    • Return Roller Quantity 5 Standard and 1 Vibrating Roller
    • Idler Roller Diameter 8 in 20.3 cm
    • Standard Drive Roller Diameter 12.8 in 32.4 cm
    • Magnetic Drive Roller Diameter 12.8 in 32.4 cm
    • Drive Motor Eaton
    • Belt Speed 778 ft/min 237.1 m/min
    • Load Height 14 ft 4.3 m
  • Hydraulic System

    • Tank capacity 90 gal 340.7 L
    • Recommended Oil HY POWER 68
    • Filtration Method In Tank Return Filters (qty 2) with suction strainer
    • Number of Coolers 1
  • Implement Hydraulics

    • Components Conveyor
    • System Type Open Loop
    • Pump Type Gear
    • Pump Flow at Maximum RPM 20.7 gpm 78.4 L/min
    • System relief pressure 3000 psi 206.8 bar
  • Tub Drive Hydraulics

    • System Type Load Sense, Pressure Compensated
    • Pump Type Axial Piston, Variable Displacement
    • Pump Flow at Maximum RPM 22.1 gpm 83.7 L/min
    • System relief pressure 3045 psi 209.9 bar
    • Motor Series Eaton VIS45
  • Clutch Hydraulics

    • Tank capacity 21 gal 79.5 L
    • Recommended Oil VMF Gold
    • Filtration Method Spin on High Pressure
    • Number of Coolers 1
    • System Type Open Loop
    • Pump Type Gear
    • Pump Flow at Maximum RPM 10.6 gpm 40.1 L/min
    • System relief pressure 260 psi 17.9 bar
  • Loader Hydraulics

    • System Type Load Sense, Pressure Compensated
    • Pump Type Axial Piston, Varible Displacement
    • Pump Flow at Maximum RPM 54.2 gpm 205.2 L/min
    • System relief pressure 3335 psi 229.9 bar
  • Electrical System

    • System Voltage 24 Volt
    • Battery Group 8-D, 1155 CCA (Qty 2)
    • System Protection Fused
  • Control Station

    • Display Type LCD Multi-Function
    • Engine Information Operational, Diagnostic and System Parameters
    • Machine Information Operational, Diagnostic and System Parameters
    • Operational Faults SAE J1939 Diagnostic Codes
    • Gauges Fuel Level, Tub Pressure, Conveyor Pressure, Auxillary Hydraulic Pressure,
    • Switches Moisture Proof, Toggle Style
  • Radio Remote Control

    • Display Type LCD Multi-Function
    • Engine Information Operational, diagnostic and system parameters
    • Machine Information Operational, diagnostic and system parameters
    • Operational Faults SAE J1939 diagnostic codes
    • Switches Sealed Membrane
    • Operating Range 300 feet
    • Battery Type (qty 6) AA Alkaline
    • Channel Setting 50 channels
  • Loader Cab

    • Display Type DP10
    • Engine Information Operational, diagnostic and system parameters
    • Machine Information Operational, diagnostic and system parameters
    • Operational Faults SAE J1939 diagnostic codes
    • Gauges Loader Hydraulic Pressure
    • Switches Moisture Proof, Toggle Style
  • Chassis

    • Frame Description Continuous I-beam
    • Hitch Type Replaceable king pin 2"
    • Fender Description Bolt On, 3/16" Formed Steel
    • Brake Type Air Actuated w/ Spring Applied Park Brake
    • Trailer Light Type 12/24 Volt LED
  • Axle/Suspension

    • Axle Type Tandom Axle Over-Slung Spring Suspension (Non-Loader)
    • Capacity 20000 lbs 9071.8 kg
    • Tires - Option One 445/50R22.5 Aluminum Hub Piloted Super Singles
    • Wheels - Option One 22.5
    • Ground Clearance - Option One 11 in 27.9 cm
  • Axle/Suspension - Option Two

    • Axle Type Triple Axle Over-Slung Spring Suspension (Non-loader and loader)
    • Capacity 20000 lbs 9071.8 kg
    • Tires - Option One 445/50R22.5 Steel Hub Piloted Super Singles
    • Wheels - Option One 22.5
    • Ground Clearance - Option One 11 in 27.9 cm
  • Loader

    • Loader Reach 27 ft 8.2 m
    • Pedestal/Cab Rotation 370 deg
    • Loader Lift Capacity at Full Reach 3500 lbs 1587.6 kg
    • Loader Lift Capacity at 10 ' (3.05 m) 12250 lbs 5556.5 kg
    • Grapple Type Multiple Tine, Continuous 360 Degree Rotation
    • Grapple Rotation 360 deg
    • Grapple Weight 1315 lbs 596.5 kg
    • Loader Controls Electric over hydraulic
    • Climate Controls A/C & Heat
    • Radio AM/FM/WB/AUX/ SIRIUS SATELLITE RADIO READY with two 4" speakers
    • Window Type 3/8" Polycarbonate
    • Front Intrusion Guard 5/8" diameter rods welded wire mesh
  • Optional Air Compressor

    • Air Compressor Brand Mi-T-M
    • Engine 13 hp Honda
    • Maximum Pressure 175 psi 12.1 bar
    • Maximum Air Flow 29 cfm .8 cmm
    • Tank capacity 30 gal 113.6 L
  • Other Options - Tub Grinder

    • Screens Optional
    • Special Tools Group Optional
    • Special Paint Optional
    • Extended Warranty Optional
    • Preventative Maintenance Optional
