The Vermeer PTX lineup is more versatile with the PTX42 walk-beside plow/trencher.

Find A Dealer Request More Info

The PTX42 joins the PTX40 and PTX44 as another option for installing fiber optic, electrical, gas, water and irrigation services for underground utility contractors, municipalities and landscaping professionals. The PTX42 offers walk-beside, pivoting hand controls, allowing operation from either side of the machine to help enable operators with precise handling. With a variety of versatile attachments, three traction options and other recognizable, reliable features included across the PTX lineup, the PTX42 is designed to give operators more options and help maximize productivity for plowing and trenching applications. Vermeer has you covered with utility versatility!

The Vermeer PTX lineup is more versatile with the PTX42 walk-beside plow/trencher.

The PTX42 joins the PTX40 and PTX44 as another option for installing fiber optic, electrical, gas, water and irrigation services for underground utility contractors, municipalities and landscaping professionals. The PTX42 offers walk-beside, pivoting hand controls, allowing operation from either side of the machine to help enable operators with precise handling. With a variety of versatile attachments, three traction options and other recognizable, reliable features included across the PTX lineup, the PTX42 is designed to give operators more options and help maximize productivity for plowing and trenching applications. Vermeer has you covered with utility versatility!

Find A Dealer Request More Info

Features & Benefits

Fuel up

The PTX42 has a 12 gal (45.4 L) fuel tank that offers longer operation time between refills to keep your operation moving forward efficiently.

Hands-on control

The PTX42 plow/trencher offers walk-beside hand controls that pivot from side to side of the machine for convenient operation and to maneuver around potential obstacles or congested spaces on a jobsite. The control placement can help minimize operator reach and maintain operator comfort.

Attachments for the job

The PTX42 has a variety of versatile attachment options, including a backhoe, trencher, plow, porta bore and two reel carriers.  Select the right attachment that best fits the needs of your operation and jobsite.

Set your speed

The electronic control allows for convenient setting of the creep speed to help optimize performance on longer distance installations, allowing productivity while helping to reduce operator fatigue, whether trenching or plowing.

Stay on track

For varying ground conditions, choose from tires or tracks - the PTX42 offers a 23 in (58.4 cm) foam-filled tire option, while the slightly larger 26 in (66 cm) air-filled tires can help with traction. A 23 in (58.4 cm) dual air-filled tire option offers stability and lower ground pressure, and a track option is well-suited for uneven terrain.

Convenient service

Perform routine maintenance, and service the machine with convenient access to service point without the removal of hood shielding.

Specifications

Compare Models
  • General Dimensions and Weights

    • Weight (basic tractor, rubber tires) 3240 lbs 1469.6 kg
    • Weight (basic tractor, rubber tires, option two) 3188 lbs 1446.1 kg
    • Weight (basic tractor, rubber tires, option three) 2940 lbs 1333.6 kg
    • Weight (basic tractor, tracks) 3840 lbs 1741.8 kg
    • Length (basic tractor, rubber tires) 84.8 in 215.4 cm
    • Length (basic tractor, rubber tires, option two) 84.8 in 215.4 cm
    • Length (basic tractor, rubber tires, option three) 84.8 in 215.4 cm
    • Length (basic tractor, tracks) 92.9 in 236 cm
    • Width (basic tractor, rubber tires) 44.5 in 113 cm
    • Width (basic tractor, rubber tires, option two) 62.4 in 158.5 cm
    • Width (basic tractor, rubber tires, option three) 48.4 in 122.9 cm
    • Width (basic tractor, tracks) 46.1 in 117.1 cm
    • Height (basic tractor, rubber tires) 53.4 in 135.6 cm
    • Height (basic tractor, rubber tires, option two) 53.4 in 135.6 cm
    • Height (basic tractor, rubber tires, option three) 54.9 in 139.4 cm
    • Height (basic tractor, tracks) 53.9 in 136.9 cm
    • Wheel Base (Centerline of Axles) 48 in 121.9 cm
    • Tread Width with Rubber Tires (Centerline to Centerline) 30.3 in 77 cm
    • Tread Width with Rubber Tires Option Two (Centerline to Centerline) 36 in 91.4 cm
    • Tread width with rubber tires option three (centerline to centerline) 39 in 99.1 cm
    • Tread Width with Rubber Tracks (Centerline to Centerline) 32.3 in 82 cm
    • Ground Clearance (rubber tires) 6.4 in 16.3 cm
    • Ground Clearance (rubber tires, option two) 6.4 in 16.3 cm
    • Ground clearance (rubber tires, option three) 7.9 in 20.1 cm
    • Ground Clearance (tracks) 6.9 in 17.5 cm
    • Angle of approach (basic tractor, rubber tires) 32 deg
    • Angle of approach (basic tractor, rubber tires, option two) 32 deg
    • Angle of approach (basic tractor, rubber tires, option three) 37 deg
    • Angle of approach (basic tractor, tracks) 81 deg
  • Engine Option One

    • Make and Model Kubota WG1605
    • Gross Horsepower (Maximum) 46.8 hp 34.9 kw
    • Maximum Torque 88.7 ft-lb 120.3 Nm
    • Number of Cylinders 4
    • Cooling Medium Liquid Cooled
    • Maximum Operating Angle (Fore/Aft)* 30 deg
    • Maximum Operating Angle (Left/Right)* 30 deg
    • Fuel Type Gas
    • Emissions rating EPA Phase 3 and CARB LSI
  • Electrical System

    • System Voltage 12 Volt
    • Battery CCA Rating 950
    • Battery Group Class 31
  • Features

    • Display R625 Remote
  • Axle Options

    • Front Axle Type Planetary
    • Rear Axle Type Planetary
    • Axle load rating (static, per axle) 14800 lbs 6713.2 kg
    • Outside Turning Diameter (Rubber Tires, Front and Rear Steer) 18.4 ft 5.6 m
    • Outside Turning Diameter (Rubber Tires Option Two, Front and Rear Steer) 20 ft 6.1 m
    • Outside turning diameter (rubber tires option three, front and rear steer) 19 ft 5.8 m
    • Outside turning diameter (tracks, front and rear steer) 18.8 ft
    • Service Brake Type Hydrostatic
    • Parking Brake Type Drum
  • Hydraulic System

    • Auxiliary pump capacity 10.4 gpm 39.4 L/min
    • Auxiliary pump relief 2500 psi 172.4 bar
    • Attachment pump capacity 24 gpm 90.8 L/min
    • Attachment pump relief 2900 psi 199.9 bar
    • Ground drive pump capacity 33.3 gpm 126.1 L/min
    • Ground drive pump relief 2900 psi 199.9 bar
  • Capacities

    • Fuel Tank 12 gal 45.4 L
    • Hydraulic Tank 9 gal 34.1 L
    • Hydraulic System 11 gal 41.6 L
    • Coolant 1.3 gal 4.7 L
  • Ground Drive - Rubber Tire

    • Maximum forward transport speed (high) 2.4 mph 3.9 km/h
    • Maximum reverse transport speed (high) 2.4 mph 3.9 km/h
    • Maximum forward creep speed (low) 127 ft/min 38.7 m/min
    • Maximum reverse creep speed (low) 127 ft/min 38.7 m/min
    • Tire size 23" (58.4 cm) x 10.5" (26.7 cm) - 12" (30.5 cm)
    • Ground pressure (basic tractor only) 15.6 psi 1.1 bar
    • Fill Option Single tire foam
  • Ground Drive - Rubber Tire Option Three

    • Maximum forward transport speed (high) 2.7 mph 4.3 km/h
    • Maximum reverse transport speed (high) 2.7 mph 4.3 km/h
    • Maximum forward creep speed (low) 143 ft/min 43.6 m/min
    • Maximum reverse creep speed (low) 143 ft/min 43.6 m/min
    • Tire size 26" (66 cm) x 12" (30.5 cm) - 12" (30.5 cm)
    • Ground pressure (basic tractor only) 13.9 psi 1 bar
    • Fill Option Single tire air
  • Ground Drive - Rubber Tire Option Two

    • Maximum forward transport speed (high) 2.4 mph 3.9 km/h
    • Maximum reverse transport speed (high) 2.4 mph 3.9 km/h
    • Maximum forward creep speed (low) 127 ft/min 38.7 m/min
    • Maximum reverse creep speed (low) 127 ft/min 38.7 m/min
    • Tire size 23" (58.4 cm) x 10.5" (26.7 cm) - 12" (30.5 cm)
    • Ground pressure (basic tractor only) 8.7 psi .6 bar
    • Fill Option Dual tire air
  • Ground Drive - Tracks

    • Ground pressure (basic tractor only) 5.8 psi .4 bar
    • Maximum forward transport speed (high) 2.4 mph 3.9 km/h
    • Maximum reverse transport speed (high) 2.4 mph 3.9 km/h
    • Maximum forward creep speed (low) 127 ft/min 38.7 m/min
    • Maximum reverse creep speed (low) 127 ft/min 38.7 m/min
    • Track Contact Length 14.4 in 36.6 cm
    • Track width 11 in 27.9 cm

Attachments

Center mount trencher

Center mount trencher

See Specs
Vibratory plow

Vibratory plow

See Specs
Reel carrier - RC44

Reel carrier - RC44

See Specs
Backhoe

Backhoe

See Specs
Porta Bore

Porta Bore

See Specs
