The D10x15 S3 Navigator® horizontal directional drill is a reliable, economical solution for small service installation — built to help increase your crew’s productivity so you can go from one job to the next faster. With significant gains in horsepower and speed and a reduction in noise, the D10x15 S3 can help you put more product in the ground in a shorter amount of time.

Power and performance

The D10x15 S3 Navigator® horizontal directional drill is a reliable, economical solution for small service installation — built to help increase your crew’s productivity so you can go from one job to the next faster. With significant gains in horsepower and speed and a reduction in noise, the D10x15 S3 can help you put more product in the ground in a shorter amount of time.

Find A Dealer Request More Info

Features & Benefits

More length per day

An increase in carriage speed of almost 11% over its predecessor allows for faster cycle times and improved jobsite productivity.

Improved rotation performance

Improved rotation performance helps boost productivity — an increase in spindle speed of up to 16% over its predecessor allows for a better mud slurry, enabling better mud flow while pulling in product in softer or reactive ground conditions.

Get to work faster

A maximum ground drive speed (forward) of up to 3.3 mph (5.3 km/h) with optional wireless remote makes it faster than the closest competitor — helping make job setup times, jobsite entry and jobsite departure go more quickly.

High rotational torque rating

A high rotational torque rating of 1500 ft-lb (2033.7 Nm) and 10,000 lb (44.5 kN) of thrust/pullback force provide the versatile power required for tough ground conditions and pulling reamers.

Compact but powerful

An almost 50% increase in tractive-effort-to-weight ratio over its predecessor enables improved tracking up and down ditches and enhanced maneuverability when fine-tuning setup and trailer positioning.

Reduced noise levels

Reduced noise levels at operator’s ear makes a quieter working environment possible — creating less neighborhood disturbance and enabling easier communication among the crew.

Small footprint

Small footprint — 4 in (10.2 cm) narrower than its closest competitor — allows the drill to easily maneuver within narrow jobsites and position side by side with a mix system on a trailer.

Specifications

Compare Models
  • General Dimensions and Weights

    • Length (Minimum Transport) 153 in 388.6 cm
    • Width (Minimum Transport) 44 in 111.8 cm
    • Height (Minimum Transport) 66 in 167.6 cm
    • Weight 7200 lbs 3265.9 kg
    • Angle of Approach 22 deg
  • Engine

    • Make and Model Deutz TD2.9
    • Fuel Type Low sulfur diesel
    • Maximum Engine RPM 2300 rpm
    • Gross Horsepower 60 hp 44.7 kw
    • Aspiration Turbocharged
    • Noise Level at Operator's Ear 86 dB(A)
    • Emissions rating Tier 4i (EU Stage IIIA)
  • Engine Option Two

    • Make and Model Deutz TD2.9
    • Fuel Type Low sulfur diesel
    • Maximum Engine RPM 2300 rpm
    • Gross Horsepower 60 hp 44.7 kw
    • Aspiration Turbocharged
    • Noise Level at Operator's Ear 86 dB(A)
    • Emissions rating Tier 4 Final (EU Stage IV)
  • Engine Option Three

    • Make and Model Deutz TD2.9
    • Fuel Type Low sulfur diesel
    • Maximum Engine RPM 2300 rpm
    • Gross Horsepower 60 hp 44.7 kw
    • Aspiration Turbocharged
    • Noise Level at Operator's Ear 87 dB(A)
    • Emissions rating Tier 4 Final (EU Stage V)
  • Operational

    • Thrust 10000 lbs 44.5 kN
    • Pullback 10000 lbs 44.5 kN
    • Maximum Carriage Speed at Maximum Engine RPM 208 ft/min 63.4 m/min
    • Maximum Spindle Torque (High at Maximum Engine RPM) 1500 ft-lb 2033.7 Nm
    • Maximum Spindle Speed at Max Engine RPM 240 rpm
    • Minimum Bore Diameter 2.5 in 6.4 cm
    • Maximum Ground Drive Speed at Maximum Engine RPM 3.3 mph 5.3 km/h
    • Guaranteed sound power (CE-rating) 103 dB(A)
  • Fluid Capacities

    • Fuel Tank 18 gal 68.1 L
    • Hydraulic System 25 gal 94.6 L
  • Hydraulic System

    • Auxiliary Pump Flow at Maximum Engine RPM 9 gpm
    • Auxiliary Pump Relief Pressure 3000 psi 206.8 bar
    • Thrust/Pullback Pump Flow at Max Engine RPM 29 gpm 109.8 L/min
    • Thrust/Pullback Pump Relief Pressure 4350 psi 299.9 bar
    • Rotation Pump Flow at Maximum Engine RPM 29 gpm 109.8 L/min
    • Rotation Pump Relief Pressure 4350 psi 299.9 bar
    • Hydraulic Supply Filter Rating 5 micron
    • Hydraulic Return Filter Rating 5 micron
  • Drilling Fluid System Option One

    • Maximum Flow 15 gpm 56.8 L/min
    • Maximum Pressure 1000 psi 68.9 bar
    • Brand FMC
    • On Board Tank Capacity 25 gal 94.6 L
  • Features

    • Breakout System Standard hyd vise
    • Flow Indicator Standard
    • Stakedown System Standard or aggressive
    • Strike Alert Standard
    • Remote Lockout Standard
  • Drill Pipe

    • Drill Rod Thread 1.66 Firestick® drill rod #200
    • Thread Type Firestick (#200)
    • Length 6 ft 1.8 m
    • Rod Diameter 1.66 in (4.3 cm)
    • Joint Inside Diameter .8 in 2 cm
    • Weight 26 lbs 11.8 kg
    • Minimum Bend Radius 95.5 ft 29.1 m
