CTX160 Mini Skid Steer

Features & Benefits

Reduced maintenance and repair needs

Providing power for a variety of applications, the 40-hp (29.8-kW) Kohler diesel engine makes the CTX160 a tool capable of tackling jobsite challenges. This Tier 4 Final unit runs on a DOC only, which can reduce maintenance and repairs.

Compact footprint

This unit is designed to get through standard residential gates and into tight access areas. With 9-in (22.9-cm) tracks, the CTX160 is 42 in (106.7 cm) in total width, offering maximized traction and low ground pressure (psi).

Dual hydraulic system

The CTX160 dual hydraulic system is capable of providing 16.7 gpm (63.2 L/min) of hydraulic flow, powering demanding attachments. Low flow offers 9.4 gpm (28 L/min) to give maximum control.

Pilot-operated ground drive

The pilot-operated ground drive enables the operator to maintain smooth control of the joystick.

Increased operator safety

The platform keeps users out of mud and debris while the operator presence system suspends ground drive and attachment motion if the operator steps off the machine.

Vertical geometry

With a vertical geometry, this machine has a lift capacity of 1600 lb (725.7 kg). This allows for a hinge pin height of 88.75 in (225.4 cm) and is capable of pushing the load further away from the machine for adequate dumping into a truck.

Specifications

Compare Models
Show Metric
  • General Dimensions and Weights

    • Design Stand-on/Track drive
    • Length with Standard Bucket 116 in 294.6 cm
    • Length without Standard Bucket 92.5 in 235 cm
    • Width with 9" (22.9 cm) Tracks 42 in 106.7 cm
    • Height 59 in 149.9 cm
    • Height (to Hinge Pin) 88.8 in 225.4 cm
    • Ground Clearance 6.8 in 17.1 cm
    • Weight (Standard Bucket, 40HP (29.8 kW) Diesel Engine, 9" (22.9 cm) Tracks) 4120 lbs 1868.8 kg
    • Weight (No Bucket, 40 HP (29.8 kW) Diesel Engine, 9" (22.9 cm) Tracks) 3850 lbs 1746.3 kg
  • Engine - Option one

  • Track Performance

  • Operational

  • Hydraulic System

Attachments

4-in-1 bucket

4-in-1 bucket

    • Model Name 4-in-1 Bucket
    • Width 42.5 in 108 cm
    • Weight 268 lbs 121.6 kg
    • Fill Capacity 5 cu ft .1 cu m
