The VXT600 vacuum truck is the newest hydrovac solution in production geared towards payload and efficiency.

Find A Dealer Request More Info
The VXT600-11 model features an upgraded capacity with 11 yd³ (10.1 m³) of debris capacity and 1,300 gal (4,921 L) of water in the central tank. The VXT600-16 model features 16 yd³ (14.6 m³) of debris capacity and 2,400 gal (9,085 L) of water. The unit features a built-in 10-degree floor slope along with a three-stage lift cylinder and a full-radius, half-moon rear door for quick and efficient unloads. These combined features make the VXT600 one of the quickest tanks on the market to empty. This unit also features the powerful Jurop Helix 6,400-cfm (181.2-m³/min) PD blower driven by the OMSI transfer case with blower clutch pack soft-start engagement.

The VXT600 vacuum truck is the newest hydrovac solution in production geared towards payload and efficiency.

The VXT600-11 model features an upgraded capacity with 11 yd³ (10.1 m³) of debris capacity and 1,300 gal (4,921 L) of water in the central tank. The VXT600-16 model features 16 yd³ (14.6 m³) of debris capacity and 2,400 gal (9,085 L) of water. The unit features a built-in 10-degree floor slope along with a three-stage lift cylinder and a full-radius, half-moon rear door for quick and efficient unloads. These combined features make the VXT600 one of the quickest tanks on the market to empty. This unit also features the powerful Jurop Helix 6,400-cfm (181.2-m³/min) PD blower driven by the OMSI transfer case with blower clutch pack soft-start engagement. Find A Dealer Request More Info

Features & Benefits

Jurop Helix 2,000 Vacuum Pump

6,400 cfm and is capable of 27 inHg (181.2 m³/min, 685.8 mmHg) PD Blower driven by the OMSI transfer case with blower soft start engagement.

Water system

The water pump is rated for 19.4 gpm @ 3,000 psi (73.4 L/min @ 20,684 kPa).

Boiler

420K BTU diesel fired boiler with coils rated at 5,000 psi (34,473 kPa).

IFM electronics

Includes an IFM CAN bus control/monitoring system.

OMSI transmission

OMSI 500-hp (373-kW) with power clutch for blower engagement that eliminates stress on transmission.

Specifications

Compare Models
Show Metric
  • Truck

    • Compatibility 11-cu-yd spoil tank option
    • Length 406 in (1031 cm)
    • Width 100 in (254 cm)
    • Height 156 in (396 cm)
    • Gross Vehicle Weight Rating (GVWR) 79000 lbs (35833.8 kg)
    • Truck model Kenworth T880
    • Engine PACCAR
    • Engine model MX-13
    • Horsepower 510 hp (380 kW)
    • Transmission Allison
  • Truck - Option two

    • Compatibility 11-cu-yd spoil tank option
    • Length 413 in (1049 cm)
    • Width 100 in (254 cm)
    • Height 156 in (396 cm)
    • Gross Vehicle Weight Rating (GVWR) 92000 lbs (41730.5 kg)
    • Truck model Mack Granite
    • Engine Mack
    • Engine model MP8
    • Horsepower 505 hp (377 kW)
    • Transmission M-drive
  • Truck - Option three

    • Compatibility 16-cu-yd spoil tank option
    • Length 466 in (1184 cm)
    • Width 100 in (254 cm)
    • Empty weight 48000 lbs (21772.4 kg)
    • Height 156 in (396 cm)
    • Gross Vehicle Weight Rating (GVWR) 105000 lbs (47627.2 kg)
    • Truck model Kenworth T880
    • Engine PACCAR
    • Engine model MX-13
    • Horsepower 510 hp (380 kW)
    • Transmission Allison
  • Truck - Option four

    • Compatibility 16-cu-yd spoil tank option
    • Length 473 in (1201 cm)
    • Width 100 in (254 cm)
    • Height 156 in (396 cm)
    • Truck model Mack Granite
    • Engine Mack
    • Engine model MP8
    • Horsepower 506 hp (377 kW)
  • Water tank

    • Compatibility 11-cu-yd spoil tank option
    • Water capacity 1300 gal (4921 kg)
    • Number of Tanks 1
    • High pressure pump flow rate 19.4 gpm (73.4 L/min)
    • High Pressure Pump 3000 psi (20,684 kPa)
    • High pressure hose length 75 ft (22.9 m)
    • Low Water Shutoff Electronic sensor indicators
  • Water tank - Option two

    • Compatibility 16-cu-yd spoil tank option
    • Water capacity 2400 gal (9085 L)
    • Number of Tanks 1
    • High pressure pump flow rate 19.2 gpm (72.7 L/min)
    • High Pressure Pump 4000 psi (275.8 bar)
    • High pressure hose length 75 ft (22.9 m)
    • Low Water Shutoff Electronic sensor indicators
  • Spoil Tank

    • Compatibility 11-cu-yd spoil tank option
    • Spoil tank capacity 11 cu-yd
    • Door type Full radius, half-moon rear door
    • Tank Lift Type 3-stage joist
  • Spoil tank - Option two

    • Compatibility 16-cu-yd spoil tank option
    • Spoil tank capacity 16 cu-yd
    • Door type Full radius, half-moon rear door
    • Tank Lift Type 3-stage joist
  • Vacuum

    • Type of Filters Cyclonic filtration
    • Hose length 25 ft (7.6 m)
    • Hose width/diameter 8 in 20.3 cm
    • Vacuum 6400 cfm (181.2 cubic m/min)
    • Vacuum blower type Jurop Helix 2000
    • Vacuum Mercury 27 in Hg (91 kPa)
  • Control panel

    • Gauges Digital on IFM processor 7-in screen
  • Boom

    • Reach 26 ft (7.9 m)
    • Hose diameter 8 in (3.14 cm)
    • Movement 300 deg rotation
    • Remote Control IFM wireless
  • Options

    • Hot box Easy Kleen - 420K BTU (standard)
    • Hydraulic centrifugal 4-in pump Optional
