All vacs include three-stage filtration using a cyclonic separator and two-micron poly filter, cam-over full-open external hydraulic door with separate door/tank raise circuit.

Find A Dealer Request More Info
All VX75 vacs include three-stage filtration using cyclonic separator and two-micron poly filter. The machines also feature a cam-over full-open external hydraulic door with separate door/tank raise circuit, in-tank cleanout system, full debris tank electronic float shutdown and secondary ball float shutoff. They also offer a 22-gal (83.3-L) fuel tank, 50-ft (15.2-m) water hose with reel, three 10-ft x 4-in (3-m x 10-cm) vacuum hose, rotary digging lance and wash wand.

All vacs include three-stage filtration using a cyclonic separator and two-micron poly filter, cam-over full-open external hydraulic door with separate door/tank raise circuit.

All VX75 vacs include three-stage filtration using cyclonic separator and two-micron poly filter. The machines also feature a cam-over full-open external hydraulic door with separate door/tank raise circuit, in-tank cleanout system, full debris tank electronic float shutdown and secondary ball float shutoff. They also offer a 22-gal (83.3-L) fuel tank, 50-ft (15.2-m) water hose with reel, three 10-ft x 4-in (3-m x 10-cm) vacuum hose, rotary digging lance and wash wand. Find A Dealer Request More Info

Features & Benefits

Three-stage cyclonic filtration

Engineered to help prolong filter and blower life, the system is suitable for wet and dry applications. The cyclones use a tuned vortex system in which the outer vortex spiral forces small particles to fall into a separate canister. The filtered stream then passes up through the inner cyclone tube and is carried to the final poly filter.

Remote drains

Remote fluid drains and grease points are centrally-located near operator controls for ease of service.

Auto-belt tensioners

Keeps proper belt tensions at all times and helps extend belt life.

Compact core drill (option)

The compact core drill allows vacuum excavation to be performed in areas where pavement or asphalt must be removed prior to potholing by cutting a uniform hole into the pavement. Its patented vacuum suction base keeps it securely in place while the hydraulic pump powers the drill. The compact core drill is capable of cutting holes 6 in (15 cm), 8 in (20 cm) or 10 in (25.4 cm) in diameter.

In-tank washdown

Delivers a high-pressure water spray to the tank interior, helping to simultaneously dump material and clean the inside of the tank. Minimizes cleanup time and makes it efficient to remove difficult debris.

Sewer jetter (option)

The J12-30 sewer jetter system turns your vacuum system into a versatile jetter/vac combination unit. The sewer jetter is available on VX75 vacuum excavators and is capable of cleaning pipes and culverts up to 12 in (45.7 cm) in diameter. The sewer jetter features an electric retract jetter reel and is controlled by a tethered remote.

Cam-over rear door

Provides a 360-degree positive seal, even under reverse pressure without additional clamping requirements. The highly reliable cam-over door has a no in-tank moving parts, so all maintenance is external.

Hydraulic boom (option)

The 4-in (10-cm) or 5-in (12.7-cm) exclusive telescoping boom maintains hose length during extension and incorporates a remote-controlled hydraulic valve for vacuum shutoff. Available with manual or hydraulic rotations.

No hassle hose

Hang the suction hose on the side of the machine when moving between jobsites instead of coiling or disconnecting it, optimizing productivity.

Specifications

Compare Models
Show Metric
  • Trailer

    • Compatibility 500-gal (1892.7-L) spoil tank option
    • Length 232 in (589 cm)
    • Width 96 in (244 cm)
    • Height 94 in (239 cm)
    • Empty weight 7130 lbs (3234 kg)
    • Gross Vehicle Weight Rating (GVWR) 14000 lbs (6350 kg)
    • Trailer axles (2) 7000 lbs (3175 kg)
    • Hitch Type Pintle
  • Trailer - Option two

    • Compatibility 800-gal (3028.3-L) spoil tank option
    • Length 265 in (673 cm)
    • Width 97.2 in (247 cm)
    • Height 97.2 in (247 cm)
    • Empty weight 9590 lbs (4350 kg)
    • Gross Vehicle Weight Rating (GVWR) 18000 lbs (8164.7 kg)
    • Trailer axles (2) 9000 lbs (4082 kg)
    • Hitch Type Pintle
  • Trailer - Option three

    • Compatibility 1200-gal (4542.5-L) spoil tank option
    • Length 259 in (658 cm)
    • Width 102 in (259 cm)
    • Height 113 in (287 cm)
    • Empty weight 12390 lbs (5620 kg)
    • Gross Vehicle Weight Rating (GVWR) 26000 lbs (11793.4 kg)
    • Trailer axles (2) 12000 lbs (5443 kg)
    • Hitch Type Pintle
  • Engine

    • Make and Model Deutz Tier 4 Final diesel
    • Horsepower 74 hp (55 kW)
    • Fuel tank capacity or type 22 gal (83.3 L)
    • Enclosure Yes
  • Water tank

    • Compatibility 500-gal (1892.7-L) spoil tank option
    • Water capacity 250 gal (946 L)
    • Number of Tanks 2
    • High pressure pump flow rate 8 gpm (34 L/min)
    • High Pressure Pump 3000 psi (206.8 bar)
    • High pressure hose length 50 ft (15 m)
    • Low Water Shutoff Electric
  • Water tank - Option two

    • Compatibility 800-gal (3028.3-L) spoil tank option
    • Water capacity 410 gal (1552 L)
    • Number of Tanks 2
    • High pressure pump flow rate 8 gpm (34 L/min)
    • High Pressure Pump 3000 psi (206.8 bar)
    • High pressure hose length 50 ft (15 m)
    • Low Water Shutoff Electric
  • Water tank - Option three

    • Compatibility 1200-gal (4542.5-L) spoil tank option
    • Water capacity 410 gal (1552 L)
    • Number of Tanks 2
    • High pressure pump flow rate 8 gpm (34 L/min)
    • High Pressure Pump 3000 psi (206.8 bar)
    • High pressure hose length 50 ft (15 m)
    • Low Water Shutoff Electric
  • Spoil Tank

    • Compatibility 500-gal (1892.7-L) spoil tank option
    • Spoil tank capacity 500 gal (1892.7 L)
    • Door type Cam-over hydraulic
    • Tank Lift Type Dual cylinder
  • Spoil tank - Option two

    • Compatibility 800-gal (3028.3-L) spoil tank option
    • Spoil tank capacity 800 gal (3028.3 L)
    • Door type Cam-over hydraulic
    • Tank Lift Type Dual cylinder
  • Spoil tank - Option three

    • Compatibility 1200-gal (4542.5-L) spoil tank option
    • Spoil tank capacity 1200 gal (4542.5 L)
    • Door type Cam-over hydraulic
    • Tank Lift Type Dual cylinder
  • Vacuum

    • Type of Filters 2 micron washable
    • Hose length (3) 10 ft (3 m)
    • Hose width/diameter 4 in 10.2 cm
    • Air flow 1200 cfm (34 cubic m/min)
    • Vacuum blower type PD blower
    • Vacuum Mercury 15 inHg (0.5 bar)
  • Control panel

    • Controls Curbside
    • Gauges Analog
  • Boom

    • Availability Optional
    • Weight 1200 lbs (544.3 kg)
    • Reach 14 ft (4.3 m)
    • Hose diameter 4 in (10.2 cm)/5 in (12.7 cm)
    • Movement 270 deg on 14-in turret bearings
    • Remote Control Wireless
  • Jetter Pump

    • Availability Optional
    • Water flow 12 gpm/18 gpm
    • Water pressure 3000 psi (206.8 bar)/2000 psi (137.9 bar)
    • Jetter hose length 500 ft 152.4 m
    • Jetter hose diameter .5 in 1.3 cm
  • Air Compressor

    • Availability Optional
    • Air Flow 185 cfm
    • Air Pressure 100 psi 6.9 bar
    • Air Hose Length 50 ft 15.2 m
    • Air Hose Size 1 in 2.5 cm
  • Options

    • Hot box Optional
    • Strong arm Optional
    • Recirculation kit Optional
    • Hydraulic jack Optional on 500-gal (1,892.7-L) spoil tank option; not available on 800-gal (3,028.3-L) and 1,200-gal (4,542.5-L) spoil tank options
    • Reverse Pressure Standard
