LS3600TX Low Speed Shredder
The single-shaft LS3600TX is the first low speed shredder from Vermeer, featuring exclusive innovations that efficiently process contaminated waste streams and help protect critical machine components. Unparalleled access to the rotor, comb and engine compartment addresses long-time industry maintenance issues.
Solving long-standing industry maintenance issues.
The single-shaft LS3600TX is the first low speed shredder from Vermeer, featuring exclusive innovations that efficiently process contaminated waste streams and help protect critical machine components. Unparalleled access to the rotor, comb and engine compartment addresses long-time industry maintenance issues.Find A Dealer Request More Info
Features & Benefits
Full rotor access
The hydraulically operated side door provides full exposure to the rotor, comb and belly conveyor to minimize maintenance time. The service area has been designed to allow you to perform maintenance without overhead obstructions.
Adjust machine functions, capture machine data and diagnose equipment fault codes — all from the full-function remote. You can spend more time in the cab throughout the day, monitor machine health and make real-time adjustments remotely, allowing you to keep things running efficiently.
Double-ended comb teeth
The LS3600TX has individual bolt-in comb teeth that have two usable edges. This helps extend the life of your teeth and minimize wear costs.
Engine bay access
The LS3600TX gives you unparalleled access to the machine. The maintenance-friendly and highly accessible engine bay design includes large access doors, multiple ladder points and a large service platform to help with ease of maintenance and serviceability.
Mechanical driveline and protection
Equipped with a reversable mechanical transmission for an efficient power transfer that maximizes productivity. A torque limiter automatically disengages the drive when max torque is experienced — helping protect critical machine components.
Serviceable belly conveyor
The belly conveyor can be removed without detaching the discharge conveyor — allowing for minimally invasive service.
General Dimensions and Lengths
- Maximum Length - Transport 28 ft 8.5 m
- Maximum length - working 47.3 ft 14.4 m
- Maximum Width (Transport) 8.3 ft 2.5 m
- Maximum Height (Transport) 11.5 ft 3.5 m
- Maximum weight 71650 lbs 32499.9 kg
Infeed Hopper System
Rotor Option One
Belly Conveyor System
Discharge Conveyor System
Belly Conveyor Hydraulics
Discharge Conveyor Hydraulics
Fan Drive Hydraulics
Radio Remote Control
More from your machine
New LS3600TX low speed shredder enables efficient recycling
The LS3600TX low speed shredder enhances recycling operations by processing diverse materials efficiently. Designed for convenient maintenance and high productivity and equipped with a powerful engine, remote control and cutting-edge technology. Read how this machine can address many industry challenges.Read more
