Our core saws are engineered to minimize public inconvenience, minimize damage to roads, sidewalks and underground infrastructure, and minimize excavation and repair costs. Built on portable, compact trailers, our core saws can be towed with a half-ton pickup truck for convenient jobsite access.

Trouver un concessionnaire Demander plus d'infos
The Vermeer CS418B core saw is designed to cut 4-in to 18-in (10-cm to 46-cm) diameter holes in hard surfaces, like asphalt and concrete, to help utility contractors locate and excavate underground utilities. The core saw is built on a portable, compact trailer measuring 137-in (348-cm) long and 69-in (175-cm) wide for ease of jobsite access and can be towed with a half-ton pickup truck. Core sawing creates minimal disruption to traffic, reduces manual labor and preserves the road integrity when compared to saw cutting. Powered by a 25-hp (19-kW) Kohler EFI engine, the core saw has a two-speed operation that can generate up to 380 rpm for varying jobsite conditions. The CS418B features an onboard water tank to cool the saw bit and can be moved into position with the telescoping and pivoting arm.

Our core saws are engineered to minimize public inconvenience, minimize damage to roads, sidewalks and underground infrastructure, and minimize excavation and repair costs. Built on portable, compact trailers, our core saws can be towed with a half-ton pickup truck for convenient jobsite access.

The Vermeer CS418B core saw is designed to cut 4-in to 18-in (10-cm to 46-cm) diameter holes in hard surfaces, like asphalt and concrete, to help utility contractors locate and excavate underground utilities. The core saw is built on a portable, compact trailer measuring 137-in (348-cm) long and 69-in (175-cm) wide for ease of jobsite access and can be towed with a half-ton pickup truck. Core sawing creates minimal disruption to traffic, reduces manual labor and preserves the road integrity when compared to saw cutting. Powered by a 25-hp (19-kW) Kohler EFI engine, the core saw has a two-speed operation that can generate up to 380 rpm for varying jobsite conditions. The CS418B features an onboard water tank to cool the saw bit and can be moved into position with the telescoping and pivoting arm. Trouver un concessionnaire Demander plus d'infos

Caractéristiques et avantages

Pivot base

Telescoping and extendable arm allows for infinite positioning of the bit.

Mast with depth gauge

Bit travel range of 24 in (61 cm) of vertical movement. Keep track of jobsite progress with depth gauge.

Proven power

Kohler 25-hp (19-kW) EFI engine for optimum fuel efficiency, reliability, starting dependibility and featuring a heavy-duty air cleaner.

Control panel

Allows for infinite hydraulic control of bit speed, rotation and travel. Two hydraulic gauges show the operator the downforce pressure and bit rotations per minute. The dual-speed motor allows for a wide speed range supporting various bit diameters and surface conditions.

Leveling jacks

Dual jacks allow for vertical placement of the bit, featuring a level located on the front of the machine for precise positioning.

Water system

The water system offers 100 gal (378.5 L) of water available for cooling the bit with variable flow up to 2.8 gpm (10.6 L/min).

Caractéristiques techniques

Comparaison des modèles
  • Poids et dimensions générales

    • Longueur 137 in 348 cm
    • Largeur 69 in 175.3 cm
    • Hauteur 81 in 205.7 cm
    • Poids (à sec) 1700 lbs 771.1 kg
    • Poids (humide) 2200 lbs 997.9 kg
    • Charge d’essieu 3500 lbs 1587.6 kg
  • Source d’alimentation

    • Moteur Kohler ECH740 Command Pro EFI, 3600 tr/min
    • Puissance brute 25 hp 18.6 kw
  • Circuit d'eau

    • Contenance du réservoir 100 gal 378.5 L
    • Type de pompe 10,6 litres/mn Sure Flow
    • Interrupteur marche/arrêt (On/Off) 12 V
    • Débit variable Oui
    • Circuit électrique pompe à diaphragme Oui
  • Opérationnel

    • Moteur de rotation 2 vitesses
    • Vitesse de rotation 0-180 tr/min, 0-360 tr/min
    • Pression d'alimentation 0-172 bars
    • Déplacement vertical du mât 61 cm monté sur remorque
    • Déport du mât - monté sur remorque 121 cm, gauche/droite
    • Diamètres des trépans de carottage 10,2 - 45,7 cm
  • Commandes

    • Relèvement du mât Hydraulique
    • Déport de mât Manuel
  • Circuit hydraulique

    • Pompe de rotation 49,6 l / 207 bar
    • Pompe auxiliaire 18,9 l / 172 bar
