The Vermeer Rancher balers are right-sized, right-priced and just right for your ranch.

Find A Dealer Request More Info
Designed for big bale performance and sensible budgets, the Rancher 6640 baler produces larger-diameter round bales that can be easily moved and fed. And now, the next generation of Rancher balers from Vermeer is here. With standard flotation tires (31x13.5L-15) and radial pin pickup clutch, the Rancher 6640 baler is right for your ranch.

The Vermeer Rancher balers are right-sized, right-priced and just right for your ranch.

Designed for big bale performance and sensible budgets, the Rancher 6640 baler produces larger-diameter round bales that can be easily moved and fed. And now, the next generation of Rancher balers from Vermeer is here. With standard flotation tires (31x13.5L-15) and radial pin pickup clutch, the Rancher 6640 baler is right for your ranch.
Find A Dealer Request More Info

Features & Benefits

User-friendly baling operation

User-friendly baling operation with the standard Bale Expert™ monitor and optional Vermeer netwrap system, which is easy to load, feed and operate. See the specifications below for additional monitor functions.

Haysaver wheels

Haysaver wheels help clean up stray hay on the edges of the windrow, and the improved design makes adjustments simple with just a few turns of the wrench.

Radial pin clutch

Radial pin clutch provides protection at the pickup for durability and reliability.

Right-sized bales

Right-sized bales, 66 in x 47 in (167.6 cm x 119.4 cm), that are big enough for feeding yet easy to handle. Right-sized balers utilize low horsepower tractors [50 hp (37.3 kW)] for lower fuel consumption.

Standard flotation tires

Standard flotation tires (31x13.5L-15) offer improved flotation for smoother handling on rough terrain over previous Rancher baler models.

Specifications

Compare Models
  • Bale Size

    • Bale Diameter 66 in 167.6 cm
    • Bale Width 47 in 119.4 cm
    • Bale Weight 1300 lbs 589.7 kg
  • Dimensions and Weights

    • Length - Standard 160 in 406.4 cm
    • Length (With Net) 181 in 459.7 cm
    • Length (With Ramp) 171 in 434.3 cm
    • Height 111 in 281.9 cm
    • Width - Standard 95 in 241.3 cm
    • Weight (Fully Optioned) 5220 lbs 2367.8 kg
    • Drawbar Weight 760 lbs 344.7 kg
  • Bale Forming Chamber

    • Type of Chamber Variable
    • Drive Roller Size Two 5.5 " (14 cm) diameter steel with 1.9 " (4.9 cm) round bearings
    • Drum Roller Size 12 " (30.5 cm) with 1.8 " (4.5 cm) hex bearings
    • Idler Roller Size 3.5 in 8.9 cm
    • Start Roller Size 4.5 in 11.4 cm
    • Number of Plys 3 ply mini rough top
    • Width of Belt 6.8 in 17.3 cm
    • Number of Belts 6
    • Type of Lace Alligator Rivet
    • Length of Belt - Long 492 in 1249.7 cm
    • Length of Belt - Short 482 in 1224.3 cm
  • Drive System

    • Driveline 80 Degree CV, 540 RPM
    • Roller Chain Single 60 and 80
    • Torque Protection - Main Input Shaft Friction clutch
    • Torque Protection - Pick-up Radial pin clutch
    • Bearing and Sprocket Configuration Round drive shafts and bearings - Hex shaft on drum
  • Tractor Requirements

    • Horsepower Required 50 hp 37.3 kw
    • Horsepower Recommended 70 hp 52.2 kw
  • Pickup

    • Width (Tooth to Tooth) 43.5 in 110.5 cm
    • Width (Hay Saver Wheels) 73 in 185.4 cm
    • Width (On Outside Flair) 58 in 147.3 cm
    • Tooth Bars 5 bar single cam track
    • Number of Teeth 40 rubber mounted double tines
    • Stripper Band Diameter 12.6 in 32 cm
    • Drive Single 60 roller chain
    • Floatation Spring
  • Standard Details

    • Bale Formation Open throat vertical chamber with drum, hydraulic/spring belt tension
    • Monitor/Controller Bale Expert
    • Machine Adjustments Pickup height and hydraulic density setting
    • Safety Equipment SMV sign, tail lights
    • Tailgate Cylinders Standard hydraulic cylinders
    • Density System 2 hydraulic cylinders and 1 spring
    • Hay Saver Wheels Widen the effective width of the pickup
    • Tire Size - Standard 31X13.5:-15
  • Bale Monitor

    • Monitor Bale Expert
    • Bale Shape Feedback (Left (L) / Center (C) / Right (R) indicators) Left, Right
    • Number of wraps per bale for Net Wrap Yes
    • Number of Start/Center/End wraps for twine Yes
    • Auto Start Advance Yes
    • Manual Override Yes
    • Pause function Yes
    • "Near Full" and "Full Bale" alarms Yes
    • Tailgate locked alarm/indicator Yes
    • Alarm on/off/volume control Yes
    • Real-time bale size data Yes
    • Real-time moisture data Optional
    • Bales per hour Yes
    • Monitor Mount Suction Cup Mount
    • Self-diagnostic monitor and sensors Yes
  • Optional Features - Twine Tie System

    • Feed Mechanism Single arm applying two twines
    • Twine Tension Adjustable spring tension plates
    • Twine Storage 4 ball twine capacity
  • Optional Features - Netwrap System

    • Feed Mechanism Friction pan feed onto main belts
    • Net Tension Brake system varies tension to maximize bales/roll of net
    • Net Width Capable of standard and over width netwrap; 48 " and 51 " (121.92 cm and 129.54 cm)
    • Net Storage One extra roll storage
  • Optional Features

    • Pickup Lift Manual lift crank
    • Safety Equipment Fire extinguisher, highway safety chain, truck wire harness
    • Bale ramp Axle bolt on spring loaded with axle pan
    • Restrictor Plates To reduce HP required in less ideal conditions
    • Miscellaneous Extended Limited Warranty Coverage
    • Hydraulic Pickup Lift Replaces manual lift crank
    • Work Lights One side and twine box compartment, set of two lights
