The 504 Pro G3 baler is how to win the day when wanting to make high-quality hay.

Find A Dealer Request More Info

Oncoming rain clouds can ruin a hay producer’s day. That’s one reason why silage is quickly becoming a preferable option for producers everywhere who are tired of waiting on good weather and want high-quality forage for their cattle. According to Michigan State University Extension, silage harvested within five days of the optimal time has a feed quality advantage of $26.46 per ton over dry hay*. For some producers, that’s reason enough to make the switch.

The Vermeer Generation 3 Pro balers were specially designed and built from the ground up in Pella, Iowa, to handle the rigors of baling wet, heavy crops — combining strength and smart features while still giving operators the versatility of having a baler that can bale dry hay.

*https://www.makinhay.com/will-baleage-pay-consider-feed-needs-economics/

The 504 Pro G3 baler is how to win the day when wanting to make high-quality hay.

Oncoming rain clouds can ruin a hay producer’s day. That’s one reason why silage is quickly becoming a preferable option for producers everywhere who are tired of waiting on good weather and want high-quality forage for their cattle. According to Michigan State University Extension, silage harvested within five days of the optimal time has a feed quality advantage of $26.46 per ton over dry hay*. For some producers, that’s reason enough to make the switch.

The Vermeer Generation 3 Pro balers were specially designed and built from the ground up in Pella, Iowa, to handle the rigors of baling wet, heavy crops — combining strength and smart features while still giving operators the versatility of having a baler that can bale dry hay.

*https://www.makinhay.com/will-baleage-pay-consider-feed-needs-economics/

Find A Dealer Request More Info

Features & Benefits

17-knife chopping system

Whether the hay is wet or dry, it’s of no use to producers when it ends up somewhere other than a cow’s mouth. The 17-knife chopping system precuts the crop, helping to minimize feed loss by giving cows smaller bites of hay to fit the size of their mouths. Pre-cut bales can also help decrease mixing time in mixers or feed grinders. Operators can select if they want to use 0, 8, 9 or 17 knives from the Atlas Pro™ control system in the cab for optimized bale density, fermentation, silage quality and digestibility.

Atlas Pro control system

The Atlas Pro™ control system helps to control the outcome of the bale from the convenience of the cab. Monitor bale shape and adjust density based on moisture, crop and customer preference for up to 50 fields. The scale kit provides real-time data to operators who need to know their bale weight for storage, to sell their hay or know if they have enough hay for their livestock.

Netwrap system

Spread net edge-to-edge with the latest netwrap system located in the back of the machine for operator convenience. Operators can monitor and adjust netwrap tension from the cab on a scale of 0 to 100 to maximize spread over the edges, depending on the type of netwrap. With the net gauge that works similarly to a gas gauge, the Atlas Pro control system helps operators anticipate when they need to load more netwrap rolls.

Heavy-duty components

Handling wet, heavy crops can put added stress on balers. To combat this and maximize durability, Pro G3 balers are built with heavy-duty components like large bearings, shafts, rollers and chains. Having 100-Diamond chain on the left and double-80-Diamond chain on the right gives operators the confidence their baler can handle the crop.

Versatility

The versatility of G3 Pro balers lets operators decide how they make hay. Bale it wet or dry. Chop the hay with 8, 9, or all 17 knives or don’t chop it at all.

Hydroflexcontrol floor

The hydroflexcontrol allows the baler floor to flex up and down depending on the size of the windrow in order to minimize blockage in the pickup. If the baler does plug, the operator can clear it by opening the floor hydraulically from the cab to clear the blockage and move the material back into the chamber, getting the operator back to work quickly.

Specifications

Compare Models
Show Metric
  • Bale Size

    • Bale Diameter 36 in - 60 in (91.4 cm - 152.4 cm)
    • Bale Width 48 in 121.9 cm
    • Maximum bale weight 2400 lbs 1088.6 kg
  • Dimensions and Weights

    • Length standard 205 in 520.7 cm
    • Height 120 in 304.8 cm
    • Width with standard tires 96 in 243.8 cm
    • Width with optional tires 112 in 284.5 cm
    • Tires Standard: 14L-16.1; Optional: 21.5L-16.1 flotation
    • Weight fully optioned 9825 lbs 4456.5 kg
  • Bale Forming Chamber

    • Drive Roller Size 7.1 in (18 cm) rubber and (1) 6.6 in (16.8 cm) steel
    • Drum roller size 9.5 in 24.1 cm
    • Idler roller size 6.6 in (16.8 cm), 4.5 in (11.4 cm)
    • Start Roller Size 8 in 20.3 cm
    • Belt Type Endless belts
    • Number of Belts 4
    • Width of Belt 11.2 in 28.4 cm
    • Length of belt (long) 433.1 in 1100.1 cm
    • Type of Lace No laces
  • Drive System

    • Driveline 540 rpm, standard lube, cut-out clutch
    • Torque protection pickup Radial pin clutch
    • Roller chains Single 60, 80, 100 and Double 80
    • Bearing and Sprocket Configuration Round and Hex drive shafts, greaseable roller bearings
  • Tractor Requirements

    • PTO horsepower minimum 80 hp 59.7 kw
    • PTO horsepower recommended 110 hp 82 kw
  • Pickup

    • Pickup type Camless wide
    • Width tooth to tooth 73 in 185.4 cm
    • Width on outside flair 78 in 198.1 cm
    • Tooth Bars 5
    • Number of Teeth (75) double rubber-mounted
    • Teeth spacing 2.5 in (6.4 cm)
    • Stripper bands Poly
    • Flotation Gauge wheels 7.10-16 HD semi-pneumatic with spring assist
    • Pickup Lift Hydraulic
    • 3-year pickup warranty Standard
  • Control system

    • Control system type Atlas Pro™ control system
    • Display 7 in (17.8 cm) color touch screen
    • Field Statistics 50 fields with names
    • Field statistics download USB
    • Bale shape indicators Standard
    • Bales per hour Standard
  • Density

    • Bale density adjustments Standard through control system monitor
    • Density readings Digital gauge
  • Bale tie system

    • Netwrap system Standard
    • Net gauge via control system Standard
    • Net tension control via control system
    • Extra roll storage Standard
  • Features

    • Bale ramp Spring-loaded
    • Grease bank Standard
    • Automatic chain lube system Optional
    • Right-hand door Standard
    • LED maintenance lights Optional
    • Fire extinguisher, safety chain Optional

Literature

See it in action

Video 1
Image 1
Video 2
Image 2
Image 4
Image 3
Image 5
Image 6
