Utility Directional Drills

Utility Directional Drills

With a complete line of horizontal directional drills, Vermeer is a market leader in underground utility installation.

Find A Dealer Request More Info

The soaring need for infrastructure development and utility installations is driving the world underground where Vermeer can be found at the forefront of the HDD market. By listening closely to the needs of horizontal directional drill (HDD) contractors, Vermeer continues to innovate HDD well-suited for fiber, electrical, gas and water installation.

With a range of size and power offerings across our drill lineup, Vermeer has made a commitment to helping utility contractors tackle jobs in the tightest spaces and most challenging soil types, including performing small-diameter installation bores in rocky ground conditions.

With a complete line of horizontal directional drills, Vermeer is a market leader in underground utility installation.

The soaring need for infrastructure development and utility installations is driving the world underground where Vermeer can be found at the forefront of the HDD market. By listening closely to the needs of horizontal directional drill (HDD) contractors, Vermeer continues to innovate HDD well-suited for fiber, electrical, gas and water installation.

With a range of size and power offerings across our drill lineup, Vermeer has made a commitment to helping utility contractors tackle jobs in the tightest spaces and most challenging soil types, including performing small-diameter installation bores in rocky ground conditions.

Find A Dealer Request More Info

Product Lineup

Show Metric

  • Products

    Thrust

    Maximum Spindle Speed at Max Engine RPM

  • D9x13 S3 Tier 4i (Stage IIIB) HDD
    Thrust 9000 lbs 40 kN
    Maximum Spindle Speed at Max Engine RPM 190 rpm 190 rpm
    See Product Compare
  • D10x15 S3 HDD
    Thrust 10000 lbs 44.5 kN
    Maximum Spindle Speed at Max Engine RPM 240 rpm 240 rpm
    See Product Compare
  • D20x22 S3 HDD
    Thrust 19500 lbs 86.7 kN
    Maximum Spindle Speed at Max Engine RPM 257 rpm 257 rpm
    See Product Compare
  • D23x30 S3 HDD
    Thrust 24000 lbs 106.8 kN
    Maximum Spindle Speed at Max Engine RPM 219 rpm 219 rpm
    See Product Compare
  • D23x30DR S3 HDD
    Thrust 24000 lbs 106.8 kN
    Maximum Spindle Speed at Max Engine RPM 200 rpm 200 rpm
    See Product Compare
  • D24 HDD
    Thrust 24700 lbs 109.9 kN
    Maximum Spindle Speed at Max Engine RPM 198 rpm 198 rpm
    See Product Compare
  • D24S HDD
    Thrust 24000 lbs 106.8 kN
    Maximum Spindle Speed at Max Engine RPM 270 rpm 270 rpm
    See Product Compare
  • D24x40 S3 HDD
    Thrust 28000 lbs 124.6 kN
    Maximum Spindle Speed at Max Engine RPM 270 rpm 270 rpm
    See Product Compare
  • D40x55 S3 HDD
    Thrust 40000 lbs 177.9 kN
    Maximum Spindle Speed at Max Engine RPM 227 rpm 227 rpm
    See Product Compare
  • D40x55DR S3 HDD
    Thrust 40000 lbs 177.9 kN
    Maximum Spindle Speed at Max Engine RPM 100 rpm 100 rpm
    See Product Compare
  • D60S HDD
    Thrust 60000 lbs 266.9 kN
    Maximum Spindle Speed at Max Engine RPM 210 rpm 210 rpm
    See Product Compare
  • D60x90 S3 HDD
    Thrust 60000 lbs 266.9 kN
    Maximum Spindle Speed at Max Engine RPM 200 rpm 200 rpm
    See Product Compare
  • D60x90S HDD
    Thrust 60000 lbs 266.9 kN
    Maximum Spindle Speed at Max Engine RPM 210 rpm 210 rpm
    See Product Compare
