When there’s tough brush-clearing work to do, you can count on a Vermeer BC1200XL to handle it.

Find A Dealer Request More Info
Available with a 110-hp (82-kW) Cummins Tier 3 diesel engine, the BC1200XL is rugged, powerful, and offers innovative features designed for safety and performance. Not only does the BC1200XL tear through material up to 12 in (30.5 cm) in diameter, its patented productivity enhancements help make the job easy.

When there’s tough brush-clearing work to do, you can count on a Vermeer BC1200XL to handle it.

Available with a 110-hp (82-kW) Cummins Tier 3 diesel engine, the BC1200XL is rugged, powerful, and offers innovative features designed for safety and performance. Not only does the BC1200XL tear through material up to 12 in (30.5 cm) in diameter, its patented productivity enhancements help make the job easy.
Find A Dealer Request More Info

Features & Benefits

Dual horizontal offset feed rollers

Get more done thanks do the aggressive feeding action of dual horizontal offset feed rollers.

SmartFeed system

Protect your engine with the SmartFeed system, which monitors engine speed and stops or reverses the feed rollers if needed.

Optional winch

Take on the heavy work with an optional winch for effortless handling of large logs.

Specifications

Compare Models
  • General Dimensions and Weights

    • Length - Feed Table Up, Tongue In 168 in 426.7 cm
    • Length - Table Down, Tongue Extended 206 in 523.2 cm
    • Width 79 in 200.7 cm
    • Height 103 in 261.6 cm
    • Weight - Engine Option One 5325 lbs 2415.4 kg
    • Weight - Engine Option Two 5300 lbs 2404 kg
    • Tongue Weight - Engine Option One 660 lbs 299.4 kg
    • Tongue Weight - Engine Option Two 660 lbs 299.4 kg
    • Length with Winch (Additional) 206 in 523.2 cm
    • Weight With Winch (Additional) 5600 lbs 2540.1 kg
    • Sound Power 120 dB(a)
    • Sound Power - Engine Option Two 120 dB(a)
    • Horsepower Options 85 and 110 hp (63.38 and 82.03 hp)
  • Cutter Drive Components - Engine Option Two

    • Number of Bearings 2
    • Bore 2.4 in 6.2 cm
    • Type Spherical roller
    • Manufacturer Linkbelt
    • Dynamic Capacity 31400 lbs 14242.8 kg
    • Static Capacity 53500 lbs 24267.2 kg
    • Belt Idler/Tensioner Yes
    • Belt Type 5V
  • Cutter Drive Components - Engine Option One

    • Number of Bearings 2
    • Bore 2.4 in 6.2 cm
    • Type Spherical roller
    • Manufacturer Linkbelt
    • Dynamic Capacity 31400 lbs 14242.8 kg
    • Static Capacity 53500 lbs 24267.2 kg
    • Belt Idler/Tensioner Yes
    • Belt Type 5V
  • Drum/Disc Cutting System

    • Material Capacity 13.3 in 33.7 cm
    • Width 20 in 50.8 cm
    • Thickness .4 in 1 cm
    • Diameter 20 in 50.8 cm
    • Speed 2000 rpm
    • Weight With Shaft 480 lbs 217.7 kg
    • Safety Lock - Number of Positions 2
    • Number of Knives 2
    • Knife Thickness .6 in 1.6 cm
    • Material A8 chipper steel
    • Useable Edges 2
    • Knife Size 0.625 " x 4.5 " x 9 " (1.59 cm x 11.43 cm x 22.86 cm)
    • Number of Bolts/Knife 4
    • Replaceable Threaded Knife Block Yes
    • Number of Paddles 5
    • Fixture Method Weld-on
    • Air Flow 2000 cfm
    • Bedknife Size 3.5 " x 17.25 " (8.89 cm x 43.82 cm)
    • Bedknife Thickness 1 in 2.5 cm
    • Bedknife Material 1018
    • Bedknife - Number of Useable Edges 4
  • Safety System

    • Bottom Feed Stop Bar Standard
    • Bottom Feed Stop Bar Diameter 2 in 5.1 cm
    • Bottom Feed Stop Bar Material Thickness 11 GA
    • Actuation Force (BFSB) 34 lbs 15.4 kg
    • Normal Sensitivity 22 deg
    • Reduced Sensitivity 12 deg
    • Reset Method Dual green hold-to-run buttons
    • Four Position Feed Control Bar Standard
    • Diameter 2 in 5.1 cm
    • Material Thickness .1 in 0.3 cm
    • Positions Four positions: Emergency Stop, Forward, Neutral, and Reverse
    • Actuation Force 34 lbs 15.4 kg
    • Green Hold to Run Button Standard
  • Engine Option One

    • Make and Model Cummins QSB3.3L Turbo Tier 4i (Stage IIIB)
    • Number of Cylinders 4
    • Gross Horsepower (Maximum) 120 hp 89.5 kw
    • Torque (Max) 306 ft-lb 414.9 Nm
    • Fuel Tank Capacity 25 gal 94.6 L
    • Max Fuel Consumption 7.1 gph 26.9 lph
    • Fuel Type Diesel
    • Air Cleaner 2-stage dry with safety element
    • Oil Filter Spin-on
    • Recommended Oil API CH-4/SJ
    • Oil Volume with Filter 9 qt 8.5 L
    • Maximum Angle of Continuous Operation 30 deg
    • Cooling Medium Liquid
    • Coolant Capacity (Engine and Radiator) 2.5 gal 9.5 L
    • Alternator 95 Amp
    • Fan 22" (55.8 cm)
    • Clutch Type Clutchless PTO
    • Clutch Drive Engagement Belt tensioner
  • Engine Option Two

    • Make and Model Cummins QSB3.3L Turbo
    • Number of Cylinders 4
    • Gross Horsepower (Maximum) 110 hp 82 kw
    • Torque (Max) 304 ft-lb 412.2 Nm
    • Fuel Tank Capacity 25 gal 94.6 L
    • Max Fuel Consumption 6.1 gph 23.1 lph
    • Fuel Type Diesel
    • Air Cleaner Two stage dry with safety element
    • Oil Filter Spin on
    • Recommended Oil API CH-4/SJ
    • Oil Volume with Filter 9 qt 8.5 L
    • Maximum Angle of Continuous Operation 30 deg
    • Coolant Capacity (Engine and Radiator) 2.5 gal 9.5 L
    • Cooling Medium Liquid
    • Alternator 95 Amp
    • Fan 20 " (50.8 cm) suction
    • Clutch Type Clutchless PTO
    • Clutch Drive Engagement Belt tensioner
  • Chassis

    • Frame Description 7 " (17.78 cm) Z channel; .25 " (0.64 cm) thickness
    • Toolbox Description No
    • Tongue Description 2.5 " x 4.5 " x 0.38 " (6.35 cm x 11.43 cm x 0.95 cm)
    • Tongue Extension Extendable 18 " (45.7 cm)
    • Hitch Type Pintle
    • Fender Description Bolt on
    • Axle/Suspension Torsion
    • Type - Option One Rubber torsional
    • Manufacturer - Option One Dexter
    • Capacity - Option One 7,000 lbs (3,175.15 kg)
    • Tires - Option One ST235/80/R16 Load Range E
    • Wheels - Option One 16 " (40.64 cm)
    • Tires - Option Two ST285/75/R16 Load Range E
    • Wheels - Option Two 16 " (40.64 cm)
    • Brake Type Electric
    • Trailer Light Type LED
  • Discharge System

    • Chute Height 104 in 264.2 cm
    • Bottom Thickness .1 in .2 cm
    • Top Thickness .1 in 0.3 cm
    • Side Wall Thickness .1 in 0.3 cm
    • Deflector Thickness .1 in 0.3 cm
    • Chute Rotation Angle 270 deg
    • Rotation Type Manual pivot with handle
    • Rotational Lock Yes
  • Hydraulic System

    • Tank capacity 12 gal 45.4 L
    • Recommended Oil Type Vermeer VMF
    • System Type Open center
    • Filtration Method 10 micron return, 100 micron suction
    • Pump Flow at Maximum RPM 4.1 gpm 15.7 L/min
    • System relief pressure 2500 psi 172.4 bar
    • Auto Reverse PSI 2500 psi 172.4 bar
    • Flow Control No
    • Directional Control Yes
    • Oil Cooler No
  • Electrical System

    • System Voltage 12 volt
    • Battery Group 31; 660 CCA
    • Standard Gauges Fuel and hour gauges
    • Deluxe Gauges Fuel, voltage, water temperature, oil pressure, and tachometer gauges
    • Switches Lower feed stop bar sensitivity, toggle
    • Controller Vermeer ACS
    • Display LED
    • Shutdown System High temperature, low pressure
    • Radio Remote Control No
  • Winch Option

    • Winch Relief System 2200 psi 151.7 bar
    • Winch Boom Structure 0.25 " (0.64 cm) Grade 50
    • Winch Input Speed 51 rpm
    • Winch Controls Forward, reverse, and free spool
    • Winch Rope 7/16 " (1.11 cm)
    • Rope Length 150 ft 45.7 m
    • Rope Line Pull 2000 lbs 907.2 kg
    • Rope Choker 0.25 " (0.64 cm)
  • Other Options

    • Special Paint Optional
    • Extended Warranty Optional
    • Preventive Maintenance Optional
  • Feed System

    • Feed Roller Orientation Horizontal
    • Number of Feed Rollers 2
    • Feed Roller Clamp Load 2650 lbs 1202 kg
    • Feed Roller Clamp Type Manual cylinder
    • Feed Roller Minimum Distance to Drum 1 in 2.5 cm
    • Feed Roller Dimension 15 " (38.1 cm)
    • Number of Knives 8
    • Weight of Feed Roller 150 lbs 68 kg
    • Feed Roller Dimension (Two) 11.14 " (28.3 cm)
    • Number of Knives (2) 12
    • Weight of Feed Roller (Option Two) 80 lbs 36.3 kg
    • Number of Feed Roller Motors 2
    • Motor Manufacturer White Hydraulics
    • Feed Speed 110 ft/min
    • Infeed Table Width 52 in 132.1 cm
    • Infeed Table Length 30.1 in 76.5 cm
    • Infeed Hopper Height 32 in 81.3 cm
    • Infeed Throat Capacity 13.25 " x 17 " (33.65 cm x 43.18 cm)
    • Pinch Point - Distance to End of Feed Table 67.4 in 171.2 cm
    • Distance from Feed Table to Ground 27.2 in 69.1 cm
    • Infeed Table Material Thickness .2 in .5 cm
