VR820 Carted Wheel Rake

Features & Benefits

Eight wheels per wing

Rake up to 20 ft (6 m) in each pass with eight wheels on each wing.

Adjustable rake without tools

No tool adjustment because raking width and angle can be changed easily without tools to increase or decrease windrow size.

Greaseable tapered roller bearings

Keep it running smooth with greaseable tapered roller bearings on the rake wheels and transport wheels.

High-clearance frame

High-clearance frame allows for heavy hay crops to pass through easily for windrow formation.

Specifications

Compare Models
Show Metric
  • Dimensions and Weights

    • Raking width minimum 16.6 ft 5.1 m
    • Raking width maximum 19 ft 5.8 m
    • Windrow width minimum 31 in 78.7 cm
    • Windrow width maximum 80 in 203.2 cm
    • Transport Width 10 ft 3 m
    • Transport Length 20 ft 6.1 m
    • Transport Height 9.4 ft 2.9 m
    • Total Weight 1370 lbs 621.4 kg
    • Tongue Weight 200 lbs 90.7 kg
    • Transport tire size ST205/75D15
    • Flotation Rubber torsion on toolbar
  • Raking components

  • Tractor Requirements

  • Features
