604 Pro G3 Baler

Oncoming rain clouds can ruin a hay producer’s day. That’s why silage is quickly becoming a preferable option for producers everywhere who are tired of waiting on good weather and want high-quality forage for their cattle. According to Michigan State University Extension, silage harvested within five days of the optimal time has a feed quality advantage of $26.46 per ton over dry hay. For some producers, that’s reason enough to make the switch.

Of course, it takes a tough baler to handle the added tonnage of high-moisture hay.

The Vermeer Generation 3 604 Pro baler was specially designed and built from the ground up in Pella, Iowa, to handle the rigors of baling wet, heavy crops — combining strength and smart features while still giving you the versatility of having a baler that can bale dry hay.

Features and benefits

  • The G3 Pro baler is designed with a solid frame, heavy-duty components like large bearings, chains and rollers and poly pickup bands to fit the needs of North American silage producers handling wet, heavy bales. Atlas Pro control system monitors hay making metrics such as bale shape and density.
  • From its chopper system knife choices of 0, 8, 9 or 17 to its heavy-duty components to its ability to bale wet or dry hay, this machine is all about versatility.
  • The new netwrap system is designed for operator convenience with netwrap now in the back and the ability to adjust netwrap tension and monitor netwrap available on the roll.
Bale Diameter 72 in 182.9 cm
Bale Width 48.4 in 122.9 cm
Bale Weight 2400 lbs 1088.6 kg
Length - Standard 213 in 541 cm
Height 120 in 304.8 cm
Width - Standard 112 in 284.5 cm
Width (With Flotation Tires) 112 in 284.5 cm
Weight (Fully Optioned) 10000 lbs 4535.9 kg
Drawbar Weight 920 lbs 417.3 kg
Type of Chamber Variable
Drive Roller Size (1) 7.1 in (18 cm) diameter, rubber covered and (1) 6.6 in (16.8 cm) in diameter, steel, all with 50 mm (1.9 in) bearings
Drum Roller Size 9.5" ribbed
Start Roller Size 8 in 20.3 cm
Number of Plys 3-ply mini rough top
Width of Belt 11.2 in 28.4 cm
Number of Belts 4
Type of Lace 472.4 in (1198.9 cm)
Driveline 80 deg CV, optional 540 rpm
Roller Chain Single 60, 80, 100 and Double 80
Torque Protection - Main Input Shaft Cut-out clutch
Torque Protection - Pick-up Radial pin clutch
Bearing and Sprocket Configuration Round and Hex drive shafts, greasable roller bearings
Horsepower Required 90 hp 67.1 kw
Horsepower Recommended 120 hp 89.5 kw
Width (Tooth to Tooth) 71 in 180.3 cm
HYDROFLEX Control Standard
Width (On Outside Flair) 74 in 188 cm
Tooth Bars 5
Number of Teeth 75 spring with 2.5 in (6.4 cm) spacing
Stripper Band Diameter 13.5 in 34.3 cm
Drive Single 60
Floatation Gauge wheels 7.10-16 HD semi-pneumatic - spring assist
Pickup Lift Hydraulic standard
Bale Formation Horizontal chamber with bottom drum
Monitor/Controller Atlas Pro™ control system
Safety Equipment SMV sign, reflectors, tail lights
Tailgate Cylinders Hydraulic cylinders, single acting
Density System Adjustable hydraulic bale density control via control system with digital gauge
Tire Size - Standard 21.5L - 16.1 tires
Monitor Atlas Pro™ control system
Bale Shape Feedback (Left (L) / Center (C) / Right (R) indicators) Left and right
Number of wraps per bale for Net Wrap Adjustable from 1.5 to 8
Manual Override Standard
Pause function Standard
"Near Full" and "Full Bale" alarms Standard
Tailgate locked alarm/indicator Standard
Alarm on/off/volume control Standard
Real-time bale size data Yes
Real-time bale weight data Optional
Bales per hour Yes
Tons per hour Optional
Monitor Mount Standard
Self-diagnostic monitor and sensors Standard
Error history Standard
Touchscreen and button control Standard
Electronic Bale Density control Standard
Dual Knife Bank Control Standard
Field Statistics 50 Fields + field names
Feed Mechanism Friction pan feed system onto main belts
Net Tension Yes
Net Width Capable of standard and over width netwrap
Net Storage 1 extra roll
Knife Protection HydroFlexControl, hydraulic accumulator
Engage/Disengage Standard
Number of Knives 17
Safety Equipment Fire extinguisher, safety chain
Miscellaneous Scale kit, automatic chain lube system
Work Lights Set of three work lights

Videos

Introducing the 604 Pro G3 Baler

Vermeer engineers in Pella, Iowa, were intentional about every design element – from how it rides in the field to how it cuts, wraps and ejects bales. The 604 Pro G3 is how you win the day when wanting to make high-quality hay. Built right, right here by Vermeer.

Images

604 Pro G3 Baler
